SKF 15X30X7 HMSA10 RG Radial shaft seal with rubber outside diameter and single sealing lip

SKF 15X30X7 HMSA10 RG shaft seal

Size：15x30x7mm

Design：HMSA10

Lip material：Nitrile rubber (NBR)

Type of outside diameter：Rubber metal reinforced

Please click "Inquire" to get more information

Availability:



Inquire

Model:
15X30X7 HMSA10 RG shaft seal
Brand:
SKF

More details

Product Description

Radial shaft seals are used between rotating and stationary machine components, or between components in relative motion. HMSA10 seals are designed with a rubber outside diameter. They have a conventional sealing lip made of elastomer. A garter spring in the seal and a non-contacting auxiliary lip optimize the sealing against the shaft also in polluted environment.

1.High pumping rate

2.Higher contamination exclusion with dust lip

3.With garter spring

4.Accommodate misalignment

Model Number	15X30X7 HMSA10 RG shaft seal
Shaft diameter	15mm
Housing bore diameter	30mm
Seal width	7mm
Weight	0.0063kg
Brand	SKF
Design	HMSA10
Operating temperature	-40 °C to 100 °C
Category	Shaft seal
